∅ (mm) | Surface | Wieve / Soft | Spring / Hard | Packing | Type |
---|---|---|---|---|---|
(N/mm2) | (N/mm2) | Weight/Roll | SUS | ||
0.3 | Bright | 650 - 800 | 2150 - 2400 | 10 -15 Kg/Spool | 201 - 304 |
0.4 | Bright | 650 - 800 | 2050 - 2300 | 10 - 15 Kg/Spool | 201 - 304 |
0.5 | Bright | 650 - 800 | 1950 - 2200 | 10 - 15 Kg/Spool | 201 - 304 |
0.6 | Bright | 650 - 800 | 1950 - 2200 | 10 - 15 Kg/Spool | 201 - 304 |
0.7 | Bright | 650 - 800 | 1950 - 2200 | 40 - 50 Kg/Coil | 201 - 304 |
0.8 | Bright | 650 - 800 | 1850 - 2100 | 40 - 50 Kg/Coil | 201 - 304 |
0.8 | Bright | 650 - 800 | 1850 - 2100 | 40 - 50 Kg/Coil | 201 - 304 - 316 |
0.9 | Bright | 650 - 800 | 1850 - 2100 | 40 - 50 Kg/Coil | 201 - 304 - 316 |
1 | Bright | 650 - 800 | 1530 - 1780 | 40 - 50 Kg/Coil | 201 - 304 - 316 |
1.2 | Bright | 650 - 800 | 1450 - 1700 | 40 - 50 Kg/Coil | 201 - 304 - 316 |
1.5 | Bright | 650 - 800 | 1450 - 1700 | 40 - 50 Kg/Coil | 201 - 304 - 316 |
2 | Bright | 650 - 800 | 1400 - 1650 | 100 Kg/Coil | 201 - 304 - 316 |
2.5 | Bright | 650 - 800 | 1320 - 1570 | 100 Kg/Coil | 201 - 304 - 316 |
3 | Bright | 650 - 800 | 1320 - 1480 | 100 Kg/Coil | 201 - 304 - 316 |
4 | Bright | 650 - 800 | 1230 - 1480 | 100 Kg/Coil | 201 - 304 |
5 | Bright | 650 - 800 | 1100 - 1350 | 100 Kg/Coils | 201 - 304 |
∅ (mm) | T/S | T/S | Elongation | Packing | Chemical Composition (%) | ||||
---|---|---|---|---|---|---|---|---|---|
(Kg/mm2) | (Mpa) | (%) | (Kg) | C | Si | Mn | P | S | |
0.3 | 270 - 280 | 2650 - 2750 | 2.8 - 3.2 | 22.60 | 0.82 | 0.19 | 0.83 | 0.014 | 0.013 |
0.4 | 265 - 275 | 2600 - 2700 | 2.9 - 3.2 | 25.80 | 0.82 | 0.19 | 0.83 | 0.014 | 0.013 |
0.5 | 265 - 275 | 2600 - 2700 | 3.0 - 3.3 | 29.50 | 0.80 | 0.24 | 0.74 | 0.012 | 0.011 |
0.6 | 250 - 260 | 2450 - 2550 | 3.1 - 3.4 | 25.40 | 0.82 | 0.19 | 0.83 | 0.014 | 0.013 |
0.8 | 245 - 255 | 2400 - 2500 | 3.1 - 3.4 | 54.80 | 0.82 | 0.19 | 0.83 | 0.014 | 0.013 |
1.0 | 235 - 245 | 2300 - 2400 | 3.2 - 3.4 | 48.80 | 0.82 | 0.19 | 0.83 | 0.014 | 0.013 |
1.2 | 215 - 221 | 2107 - 2165 | 3.4 - 3.6 | 70.00 | 0.71 | 0.21 | 0.71 | 0.02 | 0.014 |
1.5 | 181 - 187 | 1774 - 1832 | 4.1 - 4.5 | 70.00 | 0.70 | 0.21 | 0.71 | 0.03 | 0.014 |
2.0 | 175 - 181 | 1715 - 1774 | 3.7 - 3.9 | 100.00 | 0.68 | 0.20 | 0.70 | 0.02 | 0.009 |
2.5 | 165 - 167 | 1617 - 1635 | 4.3 - 4.5 | 100.00 | 0.72 | 0.20 | 0.70 | 0.008 | 0.020 |
3.0 | 149 - 153 | 1460 - 1500 | 4.5 - 4.7 | 100.00 | 0.71 | 0.20 | 0.69 | 0.009 | 0.012 |
4.0 | 135 - 139 | 1323 1362 | 4.3 - 4.7 | 100.00 | 0.74 | 0.19 | 0.71 | 0.011 | 0.014 |
