Bar & Pipe
Information
| Size | Weight (Kg) | Grade | |||
|---|---|---|---|---|---|
| 0.8 mm | 1 mm | 1.2 mm | 1.5 mm | ||
| 3/8" | 1.05 | - | - | - | 201/304 |
| 1/2" | 1.15 | 1.75 | - | - | 201/304 |
| 5/8" | 1.85 | 2.25 | 2.65 | - | 201/304 |
| 3/4" | 2.20 | 2.70 | 3.20 | 5.36 | 201/304 |
| 1" | - | 3.65 | 4.35 | 6 | 201/304 |
| 1 1/4" | 3.75 | 4.60 | 5.50 | 80 | 201/304 |
| 1 1/2" | - | 5.55 | 6.60 | 8.25 | 201/304 |
| 2" | - | 7.50 | 8.90 | 11.0 | 201/304 |
| 2 1/2" | - | - | 11.20 | 13.90 | 201/304 |
| 3" | - | - | 13.55 | 16.70 | 201/304 |
| 4" | - | - | - | 22.44 | 201/304 |
| Size | Weight (Kg) | Grade | |||
|---|---|---|---|---|---|
| 0.8 mm | 1 mm | 1.2 mm | 1.5 mm | ||
| 15 x 30 | - | 4.13 | - | - | 201/304 |
| 20 x 20 | - | 3.65 | 4.34 | - | 201/304 |
| 20 x 40 | - | - | 6.60 | - | 201/304 |
| 25 x 25 | - | 4.60 | 5.49 | - | 201/304 |
| 25 x 50 | - | - | 8.35 | - | 201/304 |
| 30 x 30 | - | 5.54 | 6.60 | 8.22 | 201/304 |
| 40 x 40 | - | - | 8.88 | 11.00 | 201/304 |
| 50 x 50 | - | - | 11.16 | 13.90 | 201/304 |
