Roofing Insulation

Information

Type Thickness Density Standard (m) Weight Weight
(inch) Kg/m3 Width Length Kg/m2 Rol
1625 1 16 1.2 30 0.4 14.4
1625 Foil 1 16 1.2 30 0.4 15.5
1650 2 16 1.2 15 0.8 14.4
1650 Foil 2 16 1.2 15 0.8 15.5
2425 1 24 1.2 30 0.6 21.6
2450 2 24 1.2 15 1.2 21.6
3225 1 32 1.2 30 0.8 28.8
3250 2 32 1.2 15 1.6 28.8
Item Unit Index Measured Figure Remarks
Volume Weight Kg/m3 10 - 96 10 - 96 GB/T 13350-2000
Average Fiber Diameter mm < 8.0 4.0 - 6.0 GB/T 13350-2000
Hydrophobic % > 98 > 98.5 JISA 9512-2000
Heat Conduct Coefficient W/m-K 0.049-0.042 0.045-0.032 GB/T 13350-2000
Incombusibility - Incombustible Qualified (Grade A) GB/T 13350-2000
Heat Absorption Coefficient - - 1.03 Product Reverberation Method 24 Kg/m32000Hz GB/J 47-83
Highest Usage Temperature °C 400 410 GB/T 13350-2000
Type Foil Type Yarn/Type Width Length Area Thickness Weight
520 Double Bubble - 1.25 m 30 m 37.5 m2 4 mm 10 Kg
550 Single Metalizing Straight 1.25 m 60 m 75 m2 0.25 mm 11.9 Kg
560 Double Metalizing Straight 1.25 m 60 m 75 m2 0.28 mm 13.4 Kg
580 Single Woven - 1.25 m 50 m 60 m2 0.15 mm 6.5 Kg
590 Double Woven - 1.25 m 50 m 60 m2 0.18 7 Kg
810 Single Foil Straight 1.25 m 60 m 75 m2 0.25 mm 13 Kg
811 Single Foil Cross 1.25 m 60 m 75 m2 0.25 13 Kg
820 Double Foil Straight 1.25 m 60 m 75 m2 0.28 mm 15 Kg
821 Double Foil Cross 1.25 m 60 m 75 m2 0.28 mm 15 Kg
831 Double Fire Retardant 1.25 m 60 m 75 m2 0.3 mm 17.5 Kg
Type Wire ∅ Type Finish Width Length Weight
75 x 75 mm 1.2 mm 3318 Galvanized 1.8 m 30 m 13.5 Kg
50 x 50 mm 2 mm 2214 Galvanized 1.8 m 30 m 53 Kg
25 x 25 mm 2 mm 1114 Galvanized 1.2 m 30 m 70 Kg
25 x 25 mm 2 mm 225k Galvanized 0.9 m 30 m 48 Kg
25 x 25 mm 1 mm 1120 Galvanized 1 m 28 m 13 Kg
